Founded in the heart of Addis Ababa, Tariku Metals has built a reputation for reliability and precision, serving as a trusted manufacturer and supplier of industrial components. Our expertise shines with our Duplex Steel S31803 forgings, which are meticulously produced to meet rigorous international standards. We understand the critical demands of modern industry, and our forged solutions are crafted to deliver exceptional performance and longevity, providing our clients across Ethiopia and beyond with the confidence that comes from superior material quality and dependable local supply.
Duplex Steel S31803 achieves its remarkable strength through a balanced microstructure of austenite and ferrite. This unique composition, rich in chromium and molybdenum but with low carbon content, grants it excellent resistance to pitting and stress corrosion cracking. Mechanically, these forgings offer a high yield strength, often double that of standard austenitic stainless steels, along with good toughness and weldability, making them a robust and versatile choice for demanding environments.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S31803 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel S31803 | 1.4462 | S31803 |
The maximum operating temperature for Duplex Steel S31803 forgings is typically around 300°C (572°F). Beyond this temperature, the material may experience reduced strength and susceptibility to stress corrosion cracking.
Duplex Steel S31803 forgings are available in various sizes, including diameters ranging from 10 mm to 800 mm, and shapes like round, square, billets, blocks, and custom configurations, based on application needs.
Yes, S31803 Duplex Steel forgings are highly resistant to corrosion, especially in chloride-rich environments. They offer excellent protection against pitting, crevice, and stress corrosion cracking, making them ideal for harsh industrial applications.
The exceptional properties of our Duplex Steel S31803 forgings make them indispensable in sectors where failure is not an option. They are widely used in the harsh conditions of chemical processing plants, oil and gas exploration equipment, and marine applications. You will also find them in critical components for power generation, desalination units, and pharmaceutical systems, wherever a combination of high strength and superior corrosion resistance is paramount for safety, efficiency, and long-term operational success.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Tariku Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Addis Ababa, Ethiopia
