Operating from the heart of Addis Ababa, Tariku Metals is a trusted local source for robust industrial solutions, specializing in the supply of premium Hastelloy C276 forgings. We understand the critical demands of modern industry, which is why we provide components renowned for their exceptional resilience. Our forged products are crafted to offer superior performance in the most challenging environments, giving Ethiopian industries a reliable partner for projects where failure is not an option.
The strength of Hastelloy C276 lies in its sophisticated nickel-molybdenum-chromium composition, which grants it a remarkable resistance to a wide spectrum of corrosive threats, including harsh chlorides and oxidizing agents. This alloy maintains excellent mechanical integrity, offering high tensile strength and outstanding toughness even after welding. These properties ensure that our forgings don’t just resist chemical attack; they are built to withstand significant pressure and stress over the long term.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C276 Forging UNS (N10276), DIN (2.4819)
ISO 9725
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Post-forging operations for Hastelloy C276 include heat treatment (such as annealing) to relieve stresses and improve mechanical properties, followed by surface finishing (like pickling or grinding) to remove oxides and enhance corrosion resistance.
To determine if Hastelloy C276 forgings meet your needs, assess their chemical composition, mechanical properties, and resistance to corrosion under the specific conditions of your application. Conduct testing such as tensile, impact, and corrosion tests for confirmation.
The ideal temperature range for forging Hastelloy C276 is between 1,900°F and 2,200°F (1,038°C to 1,204°C). This ensures proper deformation without compromising material properties.
These properties make Hastelloy C276 forgings indispensable across several demanding sectors. They are vital components in chemical processing plants, used in reactors and piping systems that handle aggressive acids. You’ll also find them in pollution control scrubbers, pharmaceutical manufacturing, and industrial wastewater treatment. For any application involving severe corrosion or high temperatures, these forgings provide a dependable solution that minimizes downtime and maximizes operational safety and efficiency.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
