Tariku Metals, a reputable manufacturer and supplier located in Addis Ababa, Ethiopia, specializes in high-quality Titanium Grade 2 Forgings tailored for industries that require exceptional corrosion resistance, strength, and reliability. With a strong focus on precision manufacturing and compliance with global standards, these forgings excel in marine, chemical, aerospace, and medical applications. Titanium Gr. 2 is celebrated for its remarkable formability, weldability, and impressive strength-to-weight ratio, making it perfect for both structural and pressure-handling components. Tariku Metals has established itself as a go-to source across Africa and beyond for durable, high-performance titanium forging solutions that guarantee longevity and efficiency.
Titanium Grade 2 Forgings are primarily made of commercially pure titanium (about 99.2%), with trace amounts of iron, carbon, nitrogen, oxygen, and hydrogen to improve their mechanical properties. They boast a tensile strength of roughly 345–450 MPa, a yield strength of around 275 MPa, and excellent elongation (≥20%). This alloy has a low density of 4.5 g/cm³, a high melting point (~1660°C), and remarkable resistance to oxidation and corrosion in both oxidizing and reducing environments. Titanium Gr. 2 also offers outstanding toughness, fatigue resistance, and biocompatibility, making it ideal for both industrial and biomedical applications.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| ASTM B381 R50400 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
The durability of Titanium Gr 2 forgings is ensured by factors like high corrosion resistance, excellent strength-to-weight ratio, superior fatigue resistance, heat treatment, proper alloy composition, and precision manufacturing processes.
Titanium Gr 2 forgings are commonly used in aerospace, chemical processing, marine, medical, automotive, and power generation industries due to their corrosion resistance, strength, and lightweight properties.
Open-die forging for Titanium Gr 2 components involves shaping the metal by pressing it between two flat dies. It allows for high strength, uniformity, and precise control, making it ideal for complex, large components.
Titanium Grade 2 Forgings find extensive use in various industries that demand a blend of corrosion resistance, lightweight design, and strength. They are frequently employed in heat exchangers, pressure vessels, condenser tubing, and piping systems within marine and chemical processing sectors. In aerospace, they are utilized in airframe structures, engine components, and fasteners due to their impressive strength-to-weight ratio. The medical field also relies on Titanium Gr. 2 for implants, surgical instruments, and prosthetics, showcasing its versatility and reliability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Tariku Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Addis Ababa, Ethiopia
