Tariku Metals, a leading manufacturer and supplier based in Addis Ababa, Ethiopia, specializes in producing premium Titanium Grade 7 Forgings. With advanced manufacturing capabilities, strict quality assurance, and a focus on customer satisfaction, Tariku Metals delivers products that meet international standards for performance and reliability. The company’s Titanium Grade 7 Forgings are known for their exceptional corrosion resistance, mechanical strength, and durability, making them suitable for demanding industrial applications. Serving clients in the chemical, marine, aerospace, and energy sectors, Tariku Metals continues to provide high-quality solutions that ensure superior performance and long service life.
Titanium Grade 7 Forgings from Tariku Metals are mainly made of titanium, with a touch of palladium (between 0.12% and 0.25%) added to boost their resistance to corrosion in both reducing and mildly oxidizing environments. These forgings are known for their excellent weldability, formability, and ductility. Typically, they showcase a tensile strength of around 370 MPa, a yield strength of 240 MPa, and an elongation of about 24%. Grade 7 merges the physical and mechanical characteristics of commercially pure titanium with outstanding corrosion resistance, making it a top choice for demanding applications in tough chemical and marine settings.n.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Yes, Titanium Grade 7 (Ti-0.2Pd) is highly corrosion-resistant, especially in harsh environments like seawater and acidic conditions, due to the addition of palladium, enhancing its ability to resist corrosion.
Titanium Grade 7 forgings are commonly used in industries like aerospace, chemical processing, marine, medical, and power generation due to their exceptional corrosion resistance, strength, and biocompatibility in challenging environments.
Titanium Grade 7 forgings are available in various sizes and shapes, including bars, billets, rings, discs, and custom configurations, typically ranging from small to large diameters for different industrial applications.
Titanium Grade 7 Forgings are a go-to choice in industries that require top-notch corrosion resistance and mechanical reliability. In the chemical processing world, you’ll find them in heat exchangers, reactors, pressure vessels, and piping systems that deal with corrosive substances. The marine sector uses these forgings in seawater service components like pumps, valves, and condenser tubes. In aerospace, they play a crucial role in lightweight structural and engine parts. Plus, they’re essential in power generation and desalination plants, where long-lasting corrosion resistance is a must. At Tariku Metals, we make sure that every forging meets strict standards for safety, efficiency, and durability, even in the toughest environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
